Product details

PRODUCT NAME:

W Type MoSi2 heating elements

PRODUCT BRIEF

MoSi2 heating elements are made of molybdenum disilicide, resistance of high temperature, anti-oxidation.

For applications where the furnace roof is particularly low, the use of horizontally mounted elements can be used. In such cases, four-shank elements might be used where the surface temperature of the element will not exceed 1800 deg C. Available in W type in 3/6, 4/9, 6/12, 9/18 and 12/24 sizes. The multi-shank elements have advantages over two-shank elements in that the hot zones are longer, therefore fewer elements can be used and the cold end losses are reduced.


  • Product overview
  • Optional Accessories
  • After-sale service
  • Inquiry

MoSi2 heating elements are made of molybdenum disilicide, resistance of high temperature, anti-oxidation. When used under high temperature oxidizing atmosphere, the surface produces a layer of bright and dense quartz (SiO2) glass film, which can protect the silicon molybdenum rod inner layer from oxidation and the silicon molybdenum rod element has unique high temperature oxidation resistance.


STA molybdenum disilicide MoSi2 heating elements are for element temperatures up to 1850°C.  MoSi2 heating elements are available as straight or bent elements in a wide range of shapes and sizes, all characterized by long life and consistent performance.


For applications where the furnace roof is particularly low, the use of horizontally mounted elements can be used. In such cases, four-shank elements might be used where the surface temperature of the element will not exceed 1800 deg C. Available in W type in 3/6, 4/9, 6/12, 9/18 and 12/24 sizes. The multi-shank elements have advantages over two-shank elements in that the hot zones are longer, therefore fewer elements can be used and the cold end losses are reduced.


The using temperature under the different atmosphere:



Atmosphere

The Maximum Using Temperature of Element

1700 Grade

1800 Grade

NO2,CO2,O2,Air

1700°C

1800°C

He,Ar,Ne

1650°C

1750°C

SO2

1600°C

1700°C

CO,H2

1500°C

1600°C

WetH2

1400°C

1500°C

DryH2

1350°C

1450°C



Recommend Surface load



Furnace Temp (C )

1400

1500

1600

1650

1700

Surface load of hot zone(w/cm2)

<18

<15

<12

<10

<8


Phiscal property

Volume Density

5.5g/cm3

Porosity

7.40%

Bending Strength

15-25kg/cm3

Water absorption

1.20%

Vickers Hardness

(HV)570kg/mm2

Heating Elongation Rate

4%
